WD Series
Water Detector
Higher Reliability, Faster Installation, Superior Accuracy | Sense the Difference
Screw, or ram-set to floor or drip pan Detects water to prevent costly damage Buy American Act Certified
Gold plated sensing electrodes for long life
Floor and wall mount options
- Reliable water detection
- Simple installation—screw, or ram-set to floor or drip pan
- Simple operation—no maintenance
- Solid-state design… no moving parts to fail
- Fully potted for water-proofing… maximum durability
Description
The WD series detects water to prevent costly damage. Unlike float systems, it utilizes solid state detection, so is not prone to mechanical failure. The WD-1 is designed for mounting on the floor, drip pans or condensate pans, as the gold plated sensing electrodes face downwards out the back of the enclosure. The WD-2 housing accommodates mounting to a wall or vertical surface, with the gold plated sensing electrodes angled to the bottom of the enclosure.
Applications
- Ideal for spot leak detection
- Computer rooms, critical equipment, restrooms or commercial kitchens
- Monitor condensate pans and drains—turn off equipment when pans reach limit
